NBR thermal insulation sheet
Specifications:
NBR thermal insulation sheet can reduce the vibration noise of air ducts produced by fans and air flow. It is especially suitable for the automated production of air ducts, simultaneous processing of air ducts and liners, or air conditioning duct end systems in commercial and other public buildings such as schools, hospitals and hotels.
Density: 60~80 KG/CBMS and 100~150 KG/CBMS
Thermal conductivity: <=0.047w/(m.k)
Application Temperature: -40 C ~ 100 C
Flame retardant: GB/T 8624 B1
Thickness: 10 mm, 20 mm, 30 mm
Width: 1000 mm
Length: 1000 mm
Color: black
Product Details
Product Characteristics and Advantages
Acoustic absorption: open pore structure combined with composite pore design to achieve effective absorption of airborne sound over a wide frequency band; the unique combination of physical properties maximizes absorption at key noise frequencies (α ≥ 0.9 absorption coefficient at 1000 HZ or above);
Transmission loss: the relatively high density and high flow resistance provide an effective barrier to sound waves;
Damping characteristics (vibration damping effect): good viscoelastic properties can effectively reduce or eliminate the resonance of the metal plate structure (such as soundproof enclosure, pipe wall, etc.), so as to reduce the structure radiation noise.
Convenient Installation: Directly glued, easy to fit with the inner wall of the duct, the corner position can also be completely fit, no need to use other fixing methods, simple cutting of materials.
Health and environmental protection: no fiber, no dust particles, no formaldehyde, low VOC S emissions.
Anti-mold and anti-bacterial: Anti-bacterial and anti-mold factor is added to prevent the growth of bacteria and mold.
With good sound absorption and vibration damping performance, our mute adiabatic slow rebound rubber material is 5db higher than the weighted sound insulation of traditional fiber-based materials of similar density, and the fit of the inner wall of the air duct can improve the sound insulation of the air duct.
